Potência RMS: 375W RMS Potência máx: 750W máx Bobina(s): BD 2x4 Ohms Diâmetro: 12 polegadas Peso: 5Kg Dados técnicos:
• Polypropylene Cone
• Foam Surround
• Dual 4 Ohm Heat Resistant Voice Coil
• Rear Vented Pole Piece
• Large Strontium Ferrite Magnet
• Rubber Magnet Cover
• For Small Sealed or Small Vented Design
Maximum Power Handling (Coils in Series) 750W
Continuous Power Handling (Coils in Series) 350W
SPL (Coils in Series) 82 dB/M
Frequency Response 30Hz - 500Hz
Woofer Cone Material Paper & Kevlar
Woofer Magnet Dual Ferrite
Woofer Basket Stamped Steel
Woofer Surround Foam Rubber
Outside Dia = 314 mm
Mounting Hole = 277 mm
Mounting Depth = 160 mm
Sensitivity = 82 dB/m
Max. Peak Music = 750 w
Continuous Power = 375 w
Nominal Impedance = 4+4 ohm
Re DC Imp (± 10%) = 3+3 ohm
Le = 1.4 mH
V.C. Diameter = 38.9 mm
V.C. Length = 27.6 mm
Air Gap = 8.0 mm
Piston Diameter = 242 mm
Sd = 459 cm2
Vas = 62.6 L
Fs = 30.1 Hz
Qts = 0.81
Qes = 0.90
Mms = 137.1 g
Rms = 3.19
BI = 13.6
Speaker Displacement = 2.9 L
Xmax = 9.35 mm
Magnet Weight = 44.80 oz
(produto não disponível)
Outras Informações
Garantia: 1 ano de fábrica
Site do fabricante Clarion: http://www.clarionbr.com.br
Observações: Prazo de envio de 7 dias úteis
